Product Description
The WHGCM 1000L industrial high-temperature reactor is a sophisticated processing vessel designed for advanced chemical applications requiring both high-pressure integrity and ease of operation. This 1000L scale system is distinguished by its integrated Electric Lifting Device, which allows for the effortless raising and lowering of the reactor head, significantly simplifying cleaning, maintenance, and material loading processes in a busy industrial environment.
Thermal efficiency is a core strength of this model, featuring an advanced Outer Coils Jacket (Limpet coil design). This configuration provides rapid and uniform heating using oil or steam, optimized for high-temperature processes up to 200 °C. The vessel is constructed from premium SS316L stainless steel for all contact parts, ensuring superior chemical compatibility and long-term durability. To maintain total process containment, the reactor utilizes the signature Magnetic Scaling Coupler, providing a 100% hermetic static seal even at working pressures of 1.0 MPa.
Safety and global compliance are paramount, with the system holding major international certifications including ASME (U Stamp), CE, and EAC. The reactor is equipped with a 7.5 kW VFD-controlled motor, offering precise agitation across a speed range of 0 to 260 r/min. Every detail, from the cooling system for the magnetic drive to the robust 3-leg support structure, is engineered for reliable, high-integrity production, making it a turnkey solution for industries demanding the highest standards of safety and operational efficiency.
Full Technical Specifications (1000L High-Temp Lifting Series)
| Specification | Vessel (Kettle / SS316L) | Outer Coils (Jacket / SS304) |
|---|---|---|
| Design Volume / Work Volume | 1200 L / 1000 L | Limpet Coil Thermal System |
| Design Pressure | 1.3 MPa (13 bar) | 0.6 MPa (6 bar) |
| Working Pressure | 1.0 MPa (10 bar) | 0.5 MPa (5 bar) |
| Design Temperature | 230 °C | 230 °C |
| Working Temperature | 200 °C | Steam or Oil heating optimized |
| Operator Assist | Integrated Electric Lifting Device (Head removal system) | |
| Motor Power & Speed | 7.5 kW with 0~260 r/min (VFD Control) | |
| Sealing Technology | Magnetic Drive Coupling (Static Seal / 100% Hermetic) | |
| Material (Contact / Shell) | Standard SS316L (Contact) / SS304 (Non-contact Jacket) | |
| Quality Standards | ASME (U-Stamp), CE (PED), EAC (GOST) Certified | |
| Support Structure | 3-Leg Platform / Leg Support (Powder Coated) | |
